SRX-800 PRO
UHF Digital Duo-Microphone System
The SRX-800 PRO has the latest wireless UHF spectrum in digital field technology and produces extremely low audio latency capabilities and distortion features. A perfect quarter-size diversity receiver is not common but plays with dual turners to support two condenser microphones and unlimited clear-signal wireless transmission, creating an uninterrupted radio environment throughout a clean channel setting. Mixed audio for audio microphones delivering high-quality sounds makes the voice experience change. Multiple frequency bands have been developed and are available for users. Carrying the most innovative features all-in-one is a user’s best choice and is expected. The system entered into success in speech and voice clarification. Ideal for sound projection, lectures and halls.
Features
- 1/4 metal casing design with deachable antenna.
- Sync mode to assign microphone channel automatically.
- One receiver supports two microphones.
- Each microphone has an independent volume control
- AF outputs and level controls
- Backlit LCD with status display for easy reading
- Add more receivers to suit changing needs
- Standalone or rack mountable.
Specifications
Specifications |
SRX-800 PRO |
Frequency range |
492~ 928 MHz (country dependent) |
Receiver module |
DLR-8 x 1 |
Adjustable channels |
8 ~ 26present channels, by frequency range |
Display status |
Channel number, signal strength |
Power requirements |
100~240 VAC / 12~15 VDC, 0.6A switching power supply |
Audio outputs |
6.3Φ(Unbalanced with Hi/Low Switch) / XLR (balanced) |
Output level |
6.3Φ:700mV (Hi) / 70mV (Low), XLR:1V |
Frequency response |
100 Hz ~ 10 kHz |
Operating range |
＞50 ~ 70 m (open field) |
Ambient temperature |
-10℃ ~ 50℃ |
Latency |
11 ms |
Dimensions (D x W x H) |
190 x 117 x 50 without antenna (mm) |
Weight |
Approx. 640 g (1.27 lbs) |
Transmitters & Receivers
Accessories
 BL-770 Rack mount kit |
 BL-771 Rack mount kit |
 BF-770 Combiner for two receivers |
